Key Features and Technical Specifications
- System: 72V 7.5KW AC System
- Motor: AQH7.5-400C (7.5KW AC Motor)
- Battery: Maintenance-free battery, 6V×12pcs
- Capacity: 200Ah×12pcs (lead-acid battery)
- Controller: Intelligent AC Controller
- Charger: Off-board charger 72V 25A, input 220V/110V
- Passenger Capacity: 14
- Range (loaded): ≥ 60km (based on flat road at 20km/h)
- Max Speed: 30km/h
- Minimum Turning Radius: 5.5m
- Max Climbing Ability (loaded): 20%
- Max Movement After Brake: <4.8m
- Kerb Mass: 1240 kg
- Gross Mass: 2150 kg
- Overall Size (L×W×H): 4960 × 1480 × 2060 mm
- Min. Ground Clearance: 180 mm
- Front Wheel Tread: 1300 mm
- Rear Wheel Tread: 1320 mm
- Wheelbase: 2680 mm
- Many Color Options
7.5 kW
Motor
XZ
Maintenance free Lithium Battery
14
Passengers
60 KM
Range when fully charged
